Description

• Easy installation
• Short circuit and over-voltage protection.
• Conventionally cooling system air.
• External LED indicators for each channel output.
• Built against electromagnetic interference filter EMI.

Protection:
• Overcurrent protection: 105 ~ 150% (rated output voltage)
• Overvoltage Protection: 1.5 times the rated voltage
• Short circuit protection: short the output voltage, with automatic reset.

Physical and Electrical Specifications:

• Approved by: IEC / EN / UL / CSA, 60950 GB4943
• Input voltage: 110 ~ 220 Vac
• Output voltage: 11.5 ~ 15 VDC. (adjustable)
• Output Current: 20 A
• Board distribution: 1 for connection of 16 cameras.
• Dimensions: 10.33 x 3.14 x 10 in.
• Operating temperature: -14 ~ 122 °F
• Net weight: 4.40 lb (2.450 Kg).
